DG150 (3 phase) (60 Hz)
US
Metric
Overview
The Cat?� spark-ignited generator sets for stationary emergency and non-emergency (demand response) applications provide a much cleaner and sustainable solution for your power needs. The ability to run on various types of gaseous fuels, adapting automatic fuel change-over and microgrid compatibility, make these products capable to power a wide range of applications.
Generator Set Specifications
Frequency
60 Hz
Natural Gas Rating
150 ekW
Emissions/Fuel Strategy
U.S. EPA Certified for Stationary Emergency and Non-Emergency Application
Voltage
208-600
Speed
1800 rpm
Engine Specifications
Engine Model
V8, 9.1L TCAC
Bore
4.30 in
109.20 mm
Stroke
4.75 in
120.70 mm
Displacement
555.30 in³
9.10 l
Compression Ratio
9.5:1
Aspiration
TCAC
Fuel System
Electronic
Generator Set Dimensions
Length
114.00 in
2896.00 mm
Width
55.00 in
1397.00 mm
Height
68.00 in
1727.00 mm
Dry Weight - Genset
4500.00 lb
1464.00 kg
Generator Set Specifications
Gas Standby Rating
Standby, Demand Response and Prime
Features
Robust Spark Ignited Engine
- Reliable, rugged, durable design
- 9.1L TCAC spark ignited dual fuel engine compatible with natural gas and propane delivers consistent performance and excellent fuel economy with lower emissions.
Self-Regulated Alternator
- Superior motor starting capability minimizes need for oversizing alternator
- Designed to match performance and output characteristics of Cat engines
- Robust Class H insulation
- High-efficiency alternators with flexible packaging and easy installation
- Ease of serviceability and longer life
Cooling System
- Designed to operate in standard ambient temperatures up to 50°C (122°F)
- Contact your Cat Dealer for specific ambient and altitude capabilities
GCCP1.2 Control Panel
- User-friendly interface and navigation
- Scalable system to meet a wide range of installation requirement
- Site-specific programming for specific customer requirements
One Safe Source
- Components used in the generator set are selected at the design stage to provide optimum package performance
- The generator set is fully assembled at a Caterpillar facility following our quality guidelines
- Each generator set package is tested before leaving the Caterpillar facility
- Cat product support, including dealer service, parts and warranty covers the entire Cat power system
Certifications
- UL2200
- IBC Seismic
- NFPA110
World Wide Product Support
- Cat dealers have over 1,800 dealer branch stores operating in 200 countries
- Your local Cat dealer provides extensive post-sale support, including maintenance and repair agreements
Standard Equipment
- Control Panel
- GCCP1.2
Optional Equipment
- Starting/Charging
- Jacket water heater
- Fuel System
- Gas Regulator
- General
- Single element or dual element air cleaner
- Circuit breaker panel, based on regional and product configuration
