XQ1140 T4 Final
Overview
Generator Set
Engine
Dimensions
Fuel Consumption
Noise rating (with enclosure)
Rental ready
Robust, durable product with a range of rental ready features to meet job requirements and applications.
Fuel/Emissions Strategy
Meets U.S. EPA Tier 4 Final emission standards and CARB certified for non-road mobile applications at all 60 Hz ratings.
Cat C18 Diesel Engines
Dual Cat C18 ACERT™ heavy-duty diesel engines. Industry proven reliability.
CAT EMCP 4.4 Digital Controls
Dual EMCP 4.4 easy to use digital controls with manual and automatic paralleling capability.
Cat LC Series Generators
Class H Insulation. Integrated voltage regular for fast response in demanding applications.
HMI Controls
Externally Mounted Color Touch-Screen HMI Control Center
Cat Connect
Remote monitoring for fleet management and asset tracking
Sound Attenuated Container
77 dBA @ 7m Sound Performance @ 75% Prime Load. 40' ISO high cube container, 9-high stack CSC certified Service and Personnel doors. Externally-accessible controls
500 hr oil change intervals
Reducing operating costs and producing less waste
Reduced Environmental Impact
110% Spill Containment of On-Board Engine Fluids.
Factory designed, built and tested
Single-source Supplier
World Wide Product Support
Supported by an industry leading global dealer network
Additional options
Two-axle, air-ride traler with anti-lock brakesystem
Extended Service interval kits
600V generator
- Cat C18 Diesel Engines
- Two Cat C18 Diesel Engines
- Reliable, rugged, durable design
- EPA Tier 4 Final and CARB Emissions Certified
- Turbocharged Aftercooled
- Aftertreatment module. DEF System
- Alternator and Alternator attachments
- 3 Phase, brushless, 12 lead, Permanent Magnet Excited
- LC6134G Frame
- Anti-condensation space heaters
- Integrated voltage regulator (IVR) with VAR/PF control
- Sized for 105°C temperature rise at 40°C ambient
- Control Panels
- Dual EMCP 4.4 Generator-Set Mounted Digital Controllers
- Externally accessible Color Touch-Screen HMI Control Center
- Manual and automatic paralleling capability
- Governing system
- Electrical governing system ADEM™ A4
- Cat Connect remote monitoring
- Provides package monitoring and management
- Cooling System
- Vertically mounted radiator with vertical airdischarge from the container
- Provides 47°C ambient capability at Prime rating
- Charging / Starting System
- UL Listed and CSA Certified 240V, 20 Amp battery charger
- Charging alternator; 24V-80A, heavy duty withintegral regulator and belt guards
- Solar maintainer for batteries
- Single electric starting motor, 24V per engine
- Fuel System
- 630-gal (2385 L) double-wall fuel tank, UL 142and ULC 601 Listed and complies with TransportCanada requirements, internal and external fuel fill
- Fuel tanks connected by fuel transfer system withfilter to allow both engines access to all fuel on-board
- Primary and secondary fuel filters
- Fuel cooler
- Air inlet system
- Heavy-duty air cleaner with precleaner, two-stagecyclonic paper with dust cup and serviceindicator
- Distribution
- Externally-accessible, Vibration Isolated, 3600A Frame, 1000 Ka, IC, 3-pole electrically operated breaker with lock out tag out provision.
- Busbar connections
- Dual customer connections
- Sound Attenuated Container
- 40' ISO high cube container
- Sound level is 76 dB(A) at 7 meters per SAEJ1074 measured at 75% prime load
- Sound attenuated air intake louvers and fivelockable personnel doors with panic release
- Lube System
- Pump, integral oil cooler, lube oil, filter, filler anddipstick, and oil sampling valve
- Oil drain line with internal brass ball valve routedto connection point accessible from exterior
- General
- Factory tested and inspected
- Full manufacturer’s warranty
- UL, NEMA, ISO, and IEEE standards
- Trailer
- Two-axle, air-ride chassis with anti-lock brake system
