Overview

Generator

Rating
27 ekW (35 kVA) Prime
Voltage
120 - 480V
Frequency
60 Hz

Engine

Engine
C2.2T

Dimensions

Width without Trailer
41.40 in
1050.00 mm
Height without Trailer
63.70 in
1617.00 mm
Length without Trailer
91.30 in
2318.00 mm
Weight
2215.00 lb
1003.00 kg

Generator

Rating
0.00 kW
0.00 kV·A
27 ekW (35 kVA)

Dimensions

Weight
1003.00 lb
2215.00 kg
Height - Without Trailer
63.70 in
1617.00 mm
Length - Without Trailer
91.30 in
2318.00 mm
Width - Without Trailer
41.40 in
1050.00 mm

Generator

Rating Standby
0.00 kW
0.00 kV·A
30 ekW (38 kVA)

Engine

Fuel
Diesel

Fuel Consumption Prime

100% Load 60Hz Prime
2.30 gal/hr
8.80 l/hr
75% Load 60Hz Prime
1.80 gal/hr
6.70 l/hr
50% Load 60Hz Prime
1.20 gal/hr
4.40 l/hr

Fuel Consumption Standby

100% Load 60Hz Standby
2.60 gal/hr
9.80 l/hr
75% Load 60Hz Standby
2.00 gal/hr
7.40 l/hr
50% Load 60Hz Standby
1.30 gal/hr
4.90 l/hr

Generator

IPP Rated 60Hz
63 dB(A)

Noise rating (with enclosure)

Sound Power @ 7 meters (23 feet) @ All Ratings
63 dB(A)

Generator

Rating Prime
27 ekW (35 kVA)
Rating Standby
30 ekW (38 kVA)

Fuel Consumption Prime

100% Load 60Hz Prime
2.30 gal/hr
8.80 l/hr
75% Load 60Hz Prime
1.80 gal/hr
6.70 l/hr
50% Load 60Hz Prime
1.20 gal/hr
4.40 l/hr

Fuel Consumption Standby

100% Load 60Hz Standby
2.60 gal/hr
9.80 l/hr
75% Load 60Hz Standby
2.00 gal/hr
7.40 l/hr
50% Load 60Hz Standby
1.30 gal/hr
4.90 l/hr

Noise rating (with enclosure)

Sound Power @ 7 meters (23 feet) @ All Ratings
63 dB(A)
Features

Rental ready

Robust, durable product with a range of rental ready features to meet job requirements and applications.

Fuel/Emissions Strategy

Meets U.S. EPA Tier 4 Final emission standards and CARB certified for non-road mobile applications at all 60 Hz ratings

Cat C2.2T Diesel Engine

Industry proven reliability

CAT EMCP4.2B digital controls

Easy to use digital controls

Cat LC Series Generator

Integrated voltage regular for fast response in demanding applications

Sound Isolated Operator panel

Improved operator comfort

Cat Connect

Remote monitoring for fleet management and asset tracking

Factory designed, built and tested

Supported by an industry leading global dealer network

500 hr oil change intervals

Reducing operating costs and producing less waste

Improved transportability

Lifting frame, 4 point lift and trailers

Power Distribution

Distribution sockets

Additional options

Synchronising controls.
Extended Service interval kits
600V generator

Standard Equipment
  • CAT C2.2T Diesel Engine
    • Heavy-duty.
      After treatment.
  • Generator
    • 1514J frame.
  • Control Panel
    • Digital EMCP4.2B set mounted controller.
  • Cat Connect remote monitoring
    • Provides package monitoring and management.
  • Cooling System
    • Package mounted radiator with vertical air discharge.
      Filled from factory.
  • Charging / Starting System
    • 12V heavy duty starting motor and charging alternator c/w battery isolator.
  • Fuel System
    • 24hr dual wall fuel tank with 3 way directional valve for external supply.
  • Air Filter
    • Cyclonic/paper with dust cup and service indicator.
  • Distribution
    • Single, robust enclosure for controls and distribution c/w 4 pole circuit breaker and safety cut off.
  • Structure
    • Heavy Duty steel base frame with integral fuel tank.
      Lifting frame and 4 point lift.
      Base frame is wider than enclosure to protect generator set during transportation.
  • Enclosure
    • Sound attenuating, galvanised steel enclosure with exceptional noise reduction performance.
  • Exhaust
    • Integrated spark arresting silencer.
  • Lube Oil
    • On engine primary and secondary oil filters. Filled from factory.
  • General
    • Factory tested and inspected.
