US
Metric

Overview

Generator

Rating
47.5ekW (60 kVA) Prime

Generator Set

Voltage
120 - 600V
Frequency
60 Hz

Engine

Engine
C3.4B
Fuel
Diesel

Dimensions

Width without Trailer
41.30 in
1049.00 mm
Height without Trailer
65.30 in
1658.00 mm

Dimensions

Length without Trailer
106.50 in
2705.00 mm

Dimensions

Weight
2877.00 lb
1305.00 kg

Generator

Rating
47.5 ekW (60 kVA)

Engine

Model
C3.4B
Type
Diesel Engine

Dimensions

Height - Without Trailer
65.30 in
1658.00 mm
Length - Without Trailer
106.50 in
2705.00 mm
Weight
1305.00 lb
2877.00 kg
Width - Without Trailer
41.30 in
1049.00 mm

Fuel Consumption Prime

100% Load 60Hz Prime
3.70 gal/hr
13.90 l/hr
75% Load 60Hz Prime
2.80 gal/hr
10.50 l/hr
50% Load 60Hz Prime
1.90 gal/hr
7.10 l/hr

Generator

IPP Rated 60Hz
63 dB(A)
IPP Rated 60Hz
63 dB(A)

Generator Set

Rating Prime
47.5 ekW (60 kVA)

Fuel Consumption

100% Load 60Hz
3.70 gal/hr
13.90 l/hr
75% Load 60Hz
2.80 gal/hr
10.50 l/hr
50% Load 60Hz
1.90 gal/hr
7.10 l/hr

Noise rating (with enclosure)

Sound Power @ 7 meters (23 feet) @ All Ratings
63 dB(A)

Dimensions

Weight with Lube Oil and Coolant, Without Trailer
1305.00 kg
2877.00 lb
Features

Rental ready

Robust, durable product with a range of rental ready features to meet job requirements and applications.

Fuel/Emissions Strategy

Meets U.S. EPA Tier 4 Final emission standards and CARB certified for non-road mobile applications at all 60 Hz ratings

Cat C3.4B Diesel Engine

Industry proven reliability

CAT EMCP4.2B digital controls

Easy to use digital controls

Cat LC Series Generator

Integrated voltage regular for fast response in demanding applications

Sound Isolated Operator panel

Improved operator comfort

Cat Connect

Remote monitoring for fleet management and asset tracking

Factory designed, built and tested

Single-source Supplier

World Wide Product Support

Supported by an industry leading global dealer network

Improved transportability

Lifting frame, 4 point lift and trailers

500 hr oil change intervals

Reducing operating costs and producing less waste

Improved transportability

Lifting frame, 4 point lift and trailers

Power Distribution

Distribution sockets

Additional options

Synchronising controls.
Extended Service interval kits
600V generator
208V 3-phase NEMA Sockets

Standard Equipment
  • CAT C3.4B Diesel Engine
    • Heavy-duty.
      After treatment.
  • Generator
    • 1514P frame.
  • Control Panel
    • Digital EMCP4.2B set mounted controller.
  • Cat Connect remote monitoring
    • Provides package monitoring and management.
  • Cooling System
    • Package mounted radiator with vertical air discharge.
      Filled from factory.
  • Charging / Starting System
    • 12V heavy duty starting motor and charging alternator c/w battery isolator.
  • Fuel System
    • 24hr dual wall fuel tank with 3 way directional valve for external supply.
  • Air Filter
    • Cyclonic/paper with dust cup and service indicator.
  • Distribution
    • Single, robust enclosure for controls and distribution c/w 4 pole circuit breaker and safety cut off.
  • Structure
    • Heavy Duty steel base frame with integral fuel tank.
      Lifting frame and 4 point lift.
      Base frame is wider than enclosure to protect generator set during transportation.
  • Enclosure
    • Sound attenuating, galvanised steel enclosure with exceptional noise reduction performance.
  • Exhaust
    • Integrated spark arresting silencer.
  • Lube Oil
    • On engine primary and secondary oil filters. Filled from factory.
  • General
    • Factory tested and inspected.
