Mobile Generator Sets

XQP200 EU Stage V

Request A Quote
US
Metric

Overview

Generator Set

Rating Prime
200 kVA
Frequency
50/60 Hz
Voltage
127 - 480 V
Fuel/Emissions Strategy
EU Stage V

Engine

Engine
C7.1 ACERT™ Diesel Engine
Fuel
Diesel

Dimensions

Width
56.00 in
1420.00 mm
Height
93.00 in
2350.00 mm
Length
161.00 in
4085.00 mm
Weight - With Lube Oil and Coolant
8049.00 lb
3651.00 kg

Fuel Consumption

100% Load 50 Hz
11.50 gal/hr
43.40 l/hr
100% Load 60 Hz
14.30 gal/hr
54.30 l/hr
75% Load 50 Hz
8.60 gal/hr
32.40 l/hr
75% Load 60 Hz
10.50 gal/hr
39.90 l/hr
Features

Rental ready

Robust, durable product with a range of rental ready features to meet job requirements and applications.

Fuel/Emissions Strategy

EU Stage V.

Cat C7.1 Diesel Engine

Industry proven reliability.

Cat EMCP 4.2B Control Panel

Easy to use digital controls.

Cat LC5114F Generator

Integrated voltage regular for fast response in demanding applications.

Robust Galvanised Enclosure

Inhibits corrosion in service. Prevents water ingress, provides security and sound attenuation.

Sound Isolated Operator Panel

Improved operator comfort.

Cat Connect

Remote monitoring for fleet management and asset tracking.

Factory Designed, Built and Tested

Single-source Supplier

World Wide Product Support

Supported by an industry leading global dealer network.

500 hr Oil Change Intervals

Reducing operating costs and producing less waste.

Improved Transportability

Drag bars, Dual point lifting frame, Fork lift pockets and 4 Point lift.

Additional Options Available

Synchronising controls. Distribution sockets. Extended Service interval kits.

Standard Equipment
  • Cat® C7 ACERT™ Diesel Engine
    • Twin Turbocharged, air-to-air aftercooler
    • Electronic ECM controlled
  • After Treatment
    • Engine Mounted Clean Emissions Module (CEM)
    • Diesel Emissions Fluid (DEF)
  • Alternator
    • LC5114F frame.
    • Coastal insulation protection
  • Control Panel
    • Digital EMCP4.2B set mounted digital controller.
  • Air Filter
    • High Efficiency two stage air cleaner, with dust cup andservice indicator
  • Cat Connect remote monitoring
    • Provides package monitoring and management.
  • Cooling System
    • Package mounted radiator with vertical air discharge. Filled from factory.
    • High ambient performance
  • Charging / Starting System
    • 24V heavy duty charging alternator with integral regulator
  • Fuel System
    • 24hr dual wall fuel tank with internal fuel fill
    • Engine mounted primary and secondary fuel filter
  • Distribution
    • Separate robust steel enclosures for control & distribution sections
    • 4 pole, 400A main circuit breaker
  • Enclosure
    • Sound attenuating, galvanised steel enclosure with exceptional noise reduction performance.
    • Sealed quarter-turn compression latches with key orpadlock capabilities
  • Lube Oil
    • On engine primary and secondary oil filters. Filled from factory.
  • General
    • Factory tested and inspected.
    • Full manufacturer's warranty,
Optional Equipment
  • Control Panel
    • ComAp InteliGen NTC, Deepsea 7320, Deepsea 8620, DEIF AGC-4
    • Syncronising capabilities
  • Distribution
    • CE socket box with integrated MCB & RCBO protection
  • Fuel Option Pack
    • Inboard mounted 3-way valve for external fuel connection, electronic fuel gauge and Bund Level Sender
  • Drains option Pack
    • Oil and coolant drains piped to baseframe
